Inducing Jet Fan

 Features

  • Application for car park system
  • High efficiency & long discharge distance
  • Low noise centrifugal impeller
  • Adjustable nozzle directions
  • Low operating costs
  • Small size, light weight & space saving
  • Filter design, easy to maintenance



CY-YDF-450




CY-YDF-550



CY-YDF-1200

Model No.

Voltage

Power

Volume

Sound

N.W.

Outer Dia.

Case Dimension

Mounting

V

W

cmh

dB

KG

mm

mm

mm

CT-YDF-450

220

90

500-550 m3/h

< 58

11

70

540*445*220

415*400

CT-YDF-550

220

150

700-750 m3/h

< 60

13

75

540*530*200

275*500

CT-YDF-1200

220

300

1300-1400 m3/h

< 65

15

75

565*570*240

285*540
